- Display
Panel Size: Wide Screen 24.1"(61.13cm) 16:10
Panel Type : IPS
True Resolution : 1920x1200
Pixel Pitch : 0.270mm
Brightness(Max) : 300 cd/㎡
ASUS Smart Contrast Ratio (ASCR) : 80000000:1
Viewing Angle (CR≧10) : 178°(H)/178°(V)
Response Time : 6ms (Gray to Gray)
Display Colors : 16.7M
- Video Feature
Trace Free Technology
SPLENDID Video Intelligence Technology
SPLENDID Video Preset Modes : 6 Modes
Color Temperature Selection : 4 Modes
Color Accuracy : △E≦ 5
Gamma adjustment : Yes (Support Gamma 2.2/1.8 )
Color Adjustment : 6-axis adjustment(R,G,B,C,M,Y)
QuickFit (modes) : Yes ( Modes)
Picture-in-Picture
Picture-by-Picture
HDCP support
- Convenient Hotkey
SPLENDID Video Preset Mode Selection
Auto. Adjustment
Input Selection
QuickFit
Dual Customizable OSD Shortcuts
- I/O Ports
Signal Input : HDMI , D-Sub, DisplayPort, DVI-D
Audio Output : 1.3
Earphone jack : 3.5mm Mini-Jack
USB Port(s) : 1 x upstream, 4 x downstream
- Signal Frequency
Analog Signal Frequency : 30~83 KHz(H)/ 50~76 Hz(V)
Digital Signal Frequency : 30~83 KHz(H)/ 50~76 Hz(V)
- Power Consumption
Power Consumption(Typical):<25.4W*
Power Saving Mode:≦1W
Power Off Mode:0W (hard switch )
Voltage:100–240V, 50/60 Hz
*the test result is not including USB port power consumption
- Mechanical Design
Chassis Colors : Black
Tilt : -5°~+20°
Swivel : Yes
Pivot : Yes
Height Adjustment : Yes
VESA Wall Mounting : 100x100mm
- Security
Kensington lock
- Dimensions
Phys. Dimension with Stand(WxHxD):557.2x416.3x235mm
Phys. Dimension without Stand(WxHxD):557.2x362.8x62mm(For VESA Wall Mount)
Box Dimension (WxHxD):681x439x292mm
- Weight
Net Weight (Esti.):6.4kg
Gross Weight (Esti.):9.9kg
- Accessories
Cable tie
DVI cable
VGA cable
Power cord
DisplayPort cable
USB 3.0 cable
Quick start guide
Support CD
Warranty Card
Color pre-calibration report
- Regulation Approval
Energy Star®, BSMI, CB, CCC, CE, C-Tick, ErP, FCC, Gost-R, ISO-9241-307, J-MOSS, Mac Compliance, PSB, RoHS, TCO5.2, TUV-Ergo, TUV-GS, UL/cUL, VCCI, WHQL (Windows 8, Windows 7), NOM
